Quality... Selection... Craftsmanship IN STOCK EXTERIOR WOOD DOORS
2 Boise Cascade Company There’s a reason why a welcome mat is placed at the foot of a door. A door is the warm greeting as you enter the home. Conversely it is the welcoming promise of the world beyond as you leave those walls behind. The closing of a door can bring comfort and security. The opening leads to possibilities and wonder. As the first and last impression, a door is not only representative of your creativity and style, but it’s something that helps transport you to and from life’s events. Choose the right door and welcome beauty, elegance, character, and of course, unparalleled quality to your life.
brosco.com 3 Nantucket® Collection........................................... 4-5 Doors with WaterBarrier® Technology.............. 6-7 Bungalow Series®........................................................8 French Doors.................................................................9 Traditional Fir Doors & Sidelights .................10-11 Dutch Doors .................................................................11 Fir Transoms ...............................................................12 Rough Openings & Unit Dimensions ..................13 Door Specs & Unit Options...............................14-15 Poplar Options .....................................................16-17 Hinge Options ............................................................18 Warranty Information..............................................19 EXPLORE MORE AT SIMPSONDOOR.COM This catalog provides a snapshot of the standard doors available from Simpson Door Company. To explore the full collection of custom capabilities and interact even further, visit our extensive website. There you can open the door to a wide web of useful tools and information. UNLOCK MORE AT SIMPSONDOOR.COM TABLE OF CONTENTS
4 Inspired by the resilient beauty of Nantucket Island, these doors combine durable wood species with uniquely engineered components and modified mortise-and-tenon joinery. The result is an all wood door that ruggedly stands up to the harshest of weather, all without sacrificing the design or beauty you want on your home. • Mortise and Tenon joinery with face-driven pins • 2-piece laminated stile and rail construction • Ovolo or Shaker Sticking • 7/8" Simulated Divided Light (SDL) with Low-E Argon Insulating Glass • Tenon and face pins same specie as door • 17/16" Innerbond Double Hip-Raised Panel or 3/4" Flat Panel • 51/2" Wide Stiles • 10-Year warranty with no building overhang required Grip Tenon Optional No Face Pin Design Standard Joinery Matching Face Pin Hardwood Tenon
brosco.com 5 F-77130 6-Panel F-77662 6-Light F-77944 9-Light F-77506 6-Light 3'-0" x 6'-8" 3'-0" x 6'-8" 3'-0" x 6'-8" 3'-0" x 6'-8" F-77660S 6-Light Arch F-77506S 6-Light 3'-0" x 6'-8" 3'-0" x 6'-8" F-77512 12-Light F-77015 15-Light 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" F-77663 2-Light F-77703 3-Light F-77705 5-Light 1'-2" x 6'-8" 1'-2" x 6'-8" 1'-2" x 6'-8" Fir Raised Panel – Ovolo Sticking Fir Raised Panel – Ovolo Sticking Fir Flat Panel – Shaker Sticking Sapele Mahogany Raised Panel – Ovolo Sticking NANTUCKET® COLLECTION SM-77282 2-Panel 3'-0" x 6'-8" SM-77701 1-Light 1'-2" x 6'-8" No Face Pins
6 WEATHER SEAL™ PROCESS Entire stile-and-rail joints coated and bonded to decrease the possibility of water infiltration ULTRABLOCK® TECHNOLOGY WATERBARRIER® TECHNOLOGY PATENT PENDING Primed Medium Density Overlay for flat surfaces PVC glazing bead and SDL bars on exterior side. Wood bars on interior side. Composite block material finger-jointed into the bottom of the stiles Innerbond® double hip-raised panels have a water-resistant primer Simpson doors with WaterBarrier offer protection in tough exposures. All doors with WaterBarrier technology come with a 5-year warranty with no building overhang required. WaterBarrier technology features a medium density overlay over the exterior surface of the door with PVC bars and glazing beads, providing a beautiful surface for paint. And all with the beauty of Douglas Fir on the inside of the door. DOORS WITH WATERBARRIER® TECHNOLOGY All doors with WaterBarrier come standard with UltraBlock® technology and Simpson's Weather Seal™ process at stile and rail joints.
brosco.com 7 WATERBARRIER® DOORS & SIDELIGHT UPGRADE ANY SPECIAL ORDER DOOR WITH WATERBARRIER® TECHNOLOGY • For more info, visit simpsondoor.com/waterbarrier F-37662U-W 6-Light F-37944U-W 9-Light F-37504U-W 4-Light F-37512U-W 12-Light 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" F-37015U-W 6-Light F-7002U-W 1-Light F-7130U-W 6-Panel 2'-6", 2'-8", 3'-0" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 3'-0" x 7'-0" F-37705U-W 5-Light 1'-0", 1'-2" x 6'-8" • Medium Density Overlay (MDO) over the exterior surface of the door (to be painted) • 17/16" Innerbond® Split-Proof Double Hip-Raised Panels • UltraBlock® Technology - 5-Year Warranty • Fir Interior Side • 13/4" Thick • 51/2" Stiles • 3/ 4" Low-E Insulated Glass • Simulated Divided Light (SDL) • 5-Year warranty with no building overhang required C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 Fir Raised Panel – Ovolo Sticking
8 F-37218U 6-Light Arch F-37228U 6-Light F-37226U 9-Light F-37219U 2-Light 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 3'-0" x 6'-8" 1'-0", 1'-2" x 6'-8" F-4416U Veneered 3'-0" x 6'-8" Solid Engineered sections glued and doweled for strength and stability. Vertical Grain Douglas Fir BUNGALOW SERIES® FIR DOORS Bungalow Series doors are offered with traditional beaded v-groove panels and divided light construction. These doors are perfect for establishing that feeling of traditional comfort. C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 • 17/16" Innerbond® Beaded V-Groove Double Hip-Raised Panels • UltraBlock® Technology - 5-Year Warranty • 13/4" Thick • 51/2" Stiles • 3/ 4" Insulated Glass • Simulated Divided Light (SDL) • 5-Year warranty
brosco.com F-37504U C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 4-Light F-37506U C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 6-Light F-37512U C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 12-Light F-37010U C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 10-Light F-37015U C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 15-Light F-7002U C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 1-Light 3'-0" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-0"★ x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-0"★, 2'-6", 2'-8", 3'-0" x 6'-8" 3'-0" x 7'-0" 3'-0" x 7'-0" F-1510 10-Light F-1515 15-Light 4-1/2" Stiles 4-1/2" Stiles 2'-0" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-6", 3'-0" x 7'-0" FIR FRENCH DOORS C: 100 M: 44 Y: 0 K:0 C: 100 M: 57 Y: 0 K:40 The right doors can really make the view. French doors have been a favorite of homeowners because they naturally connect living spaces with the outdoor settings by allowing light to pass through. Simpson's french doors can be specified with WaterBarrier® and UltraBlock® technology upgrades. • 17/16" Innerbond® Double Hip-Raised Panels • UltraBlock® Technology - 5-Year Warranty • 13/4" Thick • 51/2" Stiles • 3/4" Low-E Argon Insulating Glass • Simulated Divided Light (SDL) • 5-Year warranty 9 Performance Series Single-Pane Tempered Glass ★ 4-1/2" Stiles
10 F-37662U 6-Light F-37663U 2-Light F-37944U 9-Light F-7044U 1-Light F-7031U 1-Light Crossbuck F-37120U 4-Light 2'-8", 3'-0" x 6'-8" 1'-0", 1'-2" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 2'-6", 2'-8", 3'-0" x 6'-8" 4-1/2" Stiles 3'-0" x 6'-8" 3'-0" x 7'-0" 1'-0", 1'-2" x 7'-0" 3'-0" x 7'-0" 3'-0" x 6'-8" F-37120 Glass and Panels do not align • 17/16" Innerbond® Double Hip-Raised Panels • UltraBlock® Technology - 5-Year Warranty • 13/4" Thick • 51/2" Stiles (F-7031U 41/2" Stiles) • 3/ 4" Insulated Glass • Simulated Divided Light (SDL) • 5-Year warranty TRADITIONAL FIR DOORS & SIDELIGHTS For generations, wherever people have found themselves experiencing life, they’ve always done so venturing out of, and coming back to, their homes. Life goes through your doors, so it’s essential that you celebrate life the way you’ve always wanted. Simpson's traditional doors were made to be part of that journey, no matter where it takes you. Door Dentil Moulding available applied to any door unit. 29-3/4" 9540 2-3/4" 9541 29-3/4" 4"
brosco.com 11 F-72011 9-Light F-72013 9-Light F-74011 6-Panel F-74013 4-Panel Crossbuck 2'-6", 2'-8", 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 3'-0" x 6'-8" 3'-0" x 6'-8" F-7134U 4-Light F-7132U 2-Light F-7282U 2-Panel F-7344U 4-Panel F-7130U 6-Panel 2'-8", 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 2'-8", 3'-0" x 6'-8" 3'-0" x 7'-0" 3'-0" x 7'-0" Insulating Glass F-37703U 3-Light F-7701U 1-Light F-7702U 1-Light 0'-10", 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 6'-8" 0'-10", 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 7'-0" 1'-0", 1'-2" x 7'-0" 3/4" Low-E Argon Insulating Glass F-37703U 3-Light F-37802U 2-Light F-37803U 3-Light F-37804U 4-Light F-37705U 5-Light 0'-10", 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 6'-8" 1'-0", 1'-2" x 7'-0" 1'-0", 1'-2" x 7'-0" FIR DOORS & SIDELIGHTS FIR DUTCH DOORS UltraBlock technology adds a water-resistant composite block in the bottom of the door stiles, where water infiltration can occur in a tough exposure. Simpson's exclusive Weather Seal™ process provides additional protection against moisture penetrating the bottom rail. Nothing says Americana like a Dutch door. With this style, a single door is divided in the middle, allowing homeowners to open the top portion while keeping the bottom portion closed.
12 • Low-E Argon Insulating Glass • Simulated Divided Lights (SDL) • Primed Frame - 49/16" Wall (no casing) • All Transom Sash unprimed • All Transom Sash 12" high x 13/4" thick • Pitched Sill • Weatherstripped Simpson Exterior Transoms can be paired with a variety of Simpson doors and sidelights to create a beautiful overall door unit. FIR SASH DIMENSIONS FIR SASH NUMBER TRANSOM DESIGN DOOR COMBINATION ACTUAL TRANSOM FRAME SIZE (NO CASING) 3'-0" 41/2" F-37743-LE 3-0 Single Door with 4-1/2" Stiles 3' 1-1/2" x 13-1/2" 3'-0" 51/2" F-37753-LE 3-0 Single Door with 5-1/2" Stiles 3' 1-1/2" x 13-1/2" 6'-1" 51/2" F-37755-LE 6-0 Single Door with 5-1/2" Stiles 6' 2-1/2" x 13-1/2" 5'-3" 129/32" F-37715-LE 1-0 / 3-0 / 1-0 Door with 2 Sidelights Continuous Sill 5' 4-1/2" x 13-1/2" 5'-7" 229/32" F-37725-LE 1-2 / 3-0 / 1-2 Door with 2 Sidelights Continuous Sill 5' 8-1/2" x 13-1/2" ROUGH OPENING: Width - Same as door unit *Height - Door unit with transom applied 8'-0" *Based on 6'8" door unit with standard sill (inswing). Deduct 1-1/2" from height for public access sill unit. FIR TRANSOMS FOR WOOD ENTRY UNITS
brosco.com 13 INSWING DOOR SYSTEM - STANDARD ALUMINUM SILL - Oak & Mahogany Sill: ADD 1/2" to Height of all dimensions - Public Access Aluminum Sill: Deduct 1" from Height of all dimensions SIZE ROUGH OPENING UNIT DIMENSION NO CASING UNIT DIMENSION W/ BRICKMOULD UNIT DIMENSION W/ 1-1/16" x 3-1/2" FLAT CASING 2'-6" x 6'-8" 32-1/2" x 82-1/2" 31-3/8" x 81-3/4" 34" x 83" 37" x 84-1/2" 2'-8" x 6'-8" 34-1/2" x 82-1/2" 33-3/8" x 81-3/4" 36" x 83" 39" x 84-1/2" 3'-0" x 6'-8" 38-1/2" x 82-1/2" 37-3/8" x 81-3/4" 40" x 83" 43" x 84-1/2" 5'-0" x 6'-8" 63" x 82-1/2" 61-7/8" x 81-3/4" 64-1/2" x 83" 67-1/2" x 84-1/2" 5'-4" x 6'-8" 67" x 82-1/2" 65-7/8" x 81-3/4" 68-1/2" x 83" 71-1/2" x 84-1/2" 6'-0" x 6'-8" 75" x 82-1/2" 73-7/8" x 81-3/4" 76-1/2" x 83" 79-1/2" x 84-1/2" For 8'-0" Height Units – add 16" to all height dimensions shown. OUTSWING DOOR SYSTEM - STANDARD ALUMINUM SILL OR PUBLIC ACCESS SILL - Oak & Mahogany Sill: ADD 3/4" to Height of all dimensions - Public Access Aluminum Sill: Use Table AS IS SIZE ROUGH OPENING UNIT DIMENSION NO CASING UNIT DIMENSION W/ BRICKMOULD UNIT DIMENSION W/ 1-1/16" x 3-1/2" FLAT CASING 2'-6" x 6'-8" 32-1/2" x 81-1/2" 31-3/8" x 80-7/8" 34-1/2" x 82-3/8" 37-1/2" x 83-7/8" 2'-8" x 6'-8" 34-1/2" x 81-1/2" 33-3/8" x 80-7/8" 36-1/2" x 82-3/8" 39-1/2" x 83-7/8" 3'-0" x 6'-8" 38-1/2" x 81-1/2" 37-3/8" x 80-7/8" 40-1/2" x 82-3/8" 43-1/2" x 83-7/8" 5'-0" x 6'-8" 63" x 81-1/2" 61-7/8" x 80-7/8" 65" x 82-3/8" 68" x 83-7/8" 5'-4" x 6'-8" 67" x 81-1/2" 65-7/8" x 80-7/8" 69" x 82-3/8" 72" x 83-7/8" 6'-0" x 6'-8" 75" x 81-1/2" 73-7/8" x 80-7/8" 77" x 82-3/8" 80" x 83-7/8" For 8'-0" Height Units – add 16" to all height dimensions shown. DOOR & SIDELIGHT UNIT _ INSWING DOOR SYSTEM - STANDARD ALUMINUM SILL MULL POST OR JAMB TO JAMB - SAME WIDTH DIMENSIONS - Oak & Mahogany Sill: ADD 1/2" to Height of all dimensions - Public Access Aluminum Sill: Deduct 1" from Height of all dimensions SIZE ROUGH OPENING UNIT DIMENSION NO CASING UNIT DIMENSION W/ BRICKMOULD UNIT DIMENSION W/ 1-1/16" x 3-1/2" FLAT CASING 3'-0" x 6'-8" w/ (1) 10" Sdlt 50" x 82-1/2" 48-7/8" x 81-3/4" 51-1/2" x 83" 54-1/2" x 84-1/2" 3'-0" x 6'-8" w/ (1) 12" Sdlt 52" x 82-1/2" 50-7/8" x 81-3/4" 53-1/2" x 83" 56-1/2" x 84-1/2" 3'-0" x 6'-8" w/ (1) 14" Sdlt 54" x 82-1/2" 52-7/8" x 81-3/4" 55-1/2" x 83" 58-1/2" x 84-1/2" 3'-0" x 6'-8" w/ (2) 10" Sdlts 61-1/2" x 82-1/2" 60-3/8" x 81-3/4" 63-1/2" x 83" 66-1/2" x 84-1/2" 3'-0" x 6'-8" w/ (2) 12" Sdlts 65-1/2" x 82-1/2" 64-3/8" x 81-3/4" 67" x 83" 70" x 84-1/2" 3'-0" x 6'-8" w/ (2) 14" Sdlts 69-1/2" x 82-1/2" 68-3/8" x 81-3/4" 71" x 83" 74" x 84-1/2" For Transom Unit Height add the Transom frame height to the appropriate dimension to obtain new height. ROUGH OPENINGS & UNIT DIMENSIONS
14 STANDARD DOOR UNIT FEATURES • 49/16” Prime Wood Frame - Inswing • Limited-Lifetime Warranty • Brickmould Exterior Casing - Primed • Compression Type Weatherstripping and Corner Seals • Bulb and Fin Door Bottom • Aluminum Sill (mill finish) - with Thermal Break, Hardwood Adjustable • 4” x 4” Zinc Dichromate Hinges (dull brass color) • Single Bore 23/8” Backset (21/8” Facebore) • Double Door Units - White Aluminum Ultimate Astragal included (w Flush Bolts) SINGLE DOOR UNIT DOUBLE DOOR UNIT Specify the following when ordering: 1. Door Design, number and size 2. Swing - Left or Right Hand - Inswing or Outswing 3. Wall Thickness and Jamb Type - 4-9/16” FJ Primed (Standard) 4. Aluminum Sill - Standard 5. Type of Casing - Primed Brickmould (Standard) - Flat Casing - Entrance Trim 6. Hardware Options Specify the following when ordering: 1. Door Design, number and size 2. Swing - Left or Right Hand - Inswing or Outswing 3. Wall Thickness and Jamb Type - 4-9/16” FJ Primed (Standard) 4. Aluminum Sill - Standard 5. Type of Casing - Primed Brickmould (Standard) - Flat Casing - Entrance Trim 6. Hardware Options – Specify for one or both doors How-to-Order How-to-Order Exterior Wood Doors SINGLE DOOR UNIT How-to-order Specify the following when ordering: 1. Door Design, number and size. 2. Swing – Left or right Hand. – Inswing or Outswing. 3. Wall Thickness and Jamb Type – 49/16" FJ Primed (Std.) 4. Aluminum Sill – Standard 5. Type of Casing – Primed Brickmould (Standard) – Flat Casing – Entrance Trim 6. Hardware Options – (see below) DOUBLE DOOR UNIT How-to-order Specify the following when ordering: 1. Door Design, number and size. 2. Swing – Left or right Hand. – Inswing or Outswing. 3. Wall Thickness and Jamb Type – 49/16" FJ Primed (Std.) 4. Aluminum Sill – Standard 5. Type of Casing – Primed Brickmould (Standard) – Flat Casing – Entrance Trim 6. Hardware Options – Specify for one or both doors (see below) Handing - single door Left Hand Right Hand Left Hand Right Hand Inswing Inswing Outswing Outswing When the door opens toward you and the knob is on the left hand side, it is a LEFT HAND DOOr. When the knob is on the right, it is a rIGHT HAND DOOr. Left Hand Right Hand Left Hand Right Hand Inswing Inswing Outswing Outswing Handing - doUBle door When the door opens toward you and the knob is on the left hand side, it is a LEFT HAND DOOr. When the knob is on the right, it is a rIGHT HAND DOOr. SIDELIGHT WOOD DOOR UNIT How-to-order Specify the following when ordering: 1. Door Design, number and size. 2. Quantity of sidelights, sidelight design and size. Specify "Standard" Continuous Head & Sill System HARDWARE OPTIONS: BrOSCO offers Hinges in Plain Bearing & Ball Bearing; radius Corner & Square Corner, also Spring-type in many of the following finishes: Black US1D Zinc US2C Zinc Dichromate US2D Black Zinc DZN Left Hand Inswing Right Hand Inswing Left Hand Outswing Right Hand HANDING - SINGLE DOOR When the door opens toward you and the knob is on the left hand side, it is a LEFT HAND DOOR. When the knob is on the right, it is a RIGHT HAND DOOR. Exterior Wood Doors SINGLE DOOR UNIT How-to-order Specify the following when ordering: 1. Door Design, number and size. 2. Swing – Left or right Hand. – Inswing or Outswing. 3. Wall Thickness and Jamb Type – 49/16" FJ Primed (Std.) 4. Aluminum Sill – Standard 5. Type of Casing – Primed Brickmould (Standard) – Flat Casing – Entrance Trim 6. Hardware Options – (see below) DOUBLE DOOR UNIT How-to-order Specify the following when ordering: 1. Door Design, number and size. 2. Swing – Left or right Hand. – Inswing or Outswing. 3. Wall Thickness and Jamb Type – 49/16" FJ Primed (Std.) 4. Aluminum Sill – Standard 5. Type of Casing – Primed Brickmould (Standard) – Flat Casing – Entrance Trim 6. Hardware Options – Specify for one or both doors (see below) Handing - single door Left Hand Right Hand Left Hand Right Hand Inswing Inswing Outswing Outswing When the door opens toward you and the knob is on the left hand side, it is a LEFT HAND DOOr. When the knob is on the right, it is a rIGHT HAND DOOr. Left Hand Right Hand Left Hand Right Hand Inswing Inswing Outswing Outswing Handing - doUBle door When the door opens toward you and the knob is on the left hand side, it is a LEFT HAND DOOr. When the knob is on the right, it is a rIGHT HAND DOOr. SIDELIGHT WOOD DOOR UNIT How-to-order Specify the following when ordering: 1. Door Design, number and size. 2. Quantity of sidelights, sidelight design and size. Specify "Standard" Continuous Head & Sill System HARDWARE OPTIONS: BrOSCO offers Hinges in Plain Bearing & Ball Bearing; radius Corner & Square Corner, also Spring-type in many of the following finishes: Black US1D Zinc US2C Zinc Dichromate US2D Black Zinc DZN Left Hand Inswing Right Hand Inswing Left Hand Outswing Right Hand Outswing HANDING - DOUBLE DOOR When the door opens toward you and the knob is on the left hand side, it is a LEFT HAND DOOR. When the knob is on the right, it is a RIGHT HAND DOOR. Boise Cascade Company BASIC SET-UP UNIT
brosco.com 15 • FrameSaver Jamb and Casing • Clad-Plus II and Brickmould • Composite Jamb and Casing • Jambs and Casing: Pine, Fir, Mahogany and Oak • PVC Brickmould and Flat Casing FRAMES - JAMBS & CASING – No Rot Exterior Door Systems Protecting the base of exterior frames is the idea behind the patented FrameSaver® technology. A revolutionary wood composite material so resistant to rot and insect damage, it's guaranteed for life. With Clad-Plus II, you get the beauty of a traditional door frame and brickmould unit that is rot-free and never needs painting. CLAD-PLUS II PVC Composite Frames • Primed, Mahogany-Grained and White Cap • Twice the Screw-Holding Power • Rigid Poly-Fiber Formulation • Closed Cellular Structure • Easily Machined POPULAR OPTIONS Brosco Boise Cascade's Lockguard Security Plate adds the strength of steel to the wood jamb, at the critical location of the latchbolt and deadbolt. Forced entry results in pressure at the latchbolt. A wood frame will usually splinter in this area before the hardware fails. The Lockguard Security Plate, when attached to a wood frame along with a deadbolt, provides the best resistance to forced entry next to a steel frame. This is a standard feature with the deadbolt prep option on BROSCO Boise Cascade Single Wood Entry Units.
16 HINGE OPTIONS US1D Black US4 Satin Brass US15A Antique Nickel US10R Dark Bronze US10BD Colonial Bronze US2D Zinc Dichromate US5 Antique Brass US26 Polished Chrome 3LB Light Brasstone US10A Antique Bronze Laquered US26D Satin Chrome US32D Stainless Steel US3 Bright Brass Plated US3 Solid Brass USP Primed US15 Satin Nickel BROSCO BALDWIN EMTEK Standard Ball Bearing Spring Hinge Standard Ball Bearing Standard Ball Bearing HINGE OPTIONS: Radius Square Radius Square Radius Square Square Square Square Antique Bronze Lacquered US10A 3 – – ✓ – – – – – Antique Brass US5 3 ✓ ✓ ✓ ✓ ✓ ✓ – – Antique Nickel US15A 3 ✓ ✓ ✓ ✓ – – – – Black (Flat Black) US1D 3 ✓ ✓ – ✓ – – – – Flat Black US19 – – – ✓ – – – ✓ ✓ Bright Brass US3 3 ✓ ✓ ✓ ✓ – – ✓ ✓ Colonial Bronze US10BD 3 ✓ ✓ – – – – – – Dark Bronze US10R 3 ✓ ✓ ✓ ✓ – – – – French Antique US7 – – – – – – – ✓ – Life Solid Brass – – – – – ✓ ✓ – – Light Brass 3LB ✓ ✓ – – – – – – – Oil Rubbed Bronze US10B – – – – – ✓ ✓ ✓ ✓ Polished Chrome US26 ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ Polished Nickel – – – – – – – ✓ ✓ Primed USP ✓ – – – – – – – – Satin Brass US4 ✓ – – ✓ – – – – – Satin Chrome US26D ✓ ✓ ✓ ✓ ✓ – – – – Satin Nickel US15 ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ Solid Brass A-US3 ✓ – – – – – – – – Stainless Steel US32D ✓ – – – ✓ – – – – Zinc Dichromate US2D ✓ – ✓ ✓ ✓ – – – – Hinges are available in Plain Bearing, Ball Bearing and Spring; Radius and Square. Variances in photography and printing may cause the finish colors shown to vary from the actual finishes. Any hinge can be converted to "Non-Removable Pin".
brosco.com 17 Add a distinctive and elegant touch to your door hinges. Choose from a wide variety of finishes. • White and Fir Multi-Point Locking Systems – Ultimate Flip Astragal – • Door Viewer - Bright Brass, Satin Nickel, Dark Bronze, Satin Chrome • Mailslot - Bright Brass, Satin Nickel, Aged Bronze, Satin Chrome, Stainless Steel • Brass Kickplate Hardware – Patented Spring- Loaded Floating Boot Lower Multi-Point Lock Pawl 4-Way Adjustable Strike Simple Solution™ Corner Pad Flip Lever Activates Floating Boot Multi-Point Lock Actuator • Brass, Bronze and Satin Nickel Aluminum • Oak, White Oak and Mahogany • Composite Aluminum Sills - Bronze, Mill • WeatherOut Flashing Sills – Full Length Mortised Lock Mechanism München 3955 München 3965 Verona 3955 Verona 3965 Finials – • Multi-Point Lock features narrow 7/8" profile for “proud edge” door panels (Single and French active panels). Available in Stainless Steel and Victorian Bronze. • Eclipse Door Handle - Victorian Bronze, Satin Nickel, Black & Brass • Works with Universal off the shelf hardware • Compatible with any hardware style • One key operates three locking bolts – triple security • Bronze or Brushed Clear Anodized • Affordably priced • Add extra security and strength to your door with a Hoppe® Multi-point Lock System • Polished Brass, Rustic Umber, Satin Nickel Ball Trilennium® 3070 Pano-Lock™ HARDWARE OPTIONS
18 SIMPSON® LIMITED WARRANTY For additional information, please visit: simpsondoor.com/warranties 1. When hanging the door, allow adequate clearance for swelling of door or frame in damp weather. Allow approximately 3/16" clearance from swelling when the door is installed in fully dry conditions. Jambs must be plumb. 2. Do not cut doors down in height by more than 2" (1-1/2" maximum from bottom or 1" on doors with UltraBlock® technology, 1/2" maximum from top). Care should be taken in cutting doors down in width to avoid exposing engineered components. Use a sharp fine-tooth saw for trimming ends of doors. 3. Caution must be used to avoid impairing the strength of the door when fitting for locks. Allow at least 1" of wood back of mortise. 4. Use three hinges on doors up to 7' in height and four hinges on doors over 7'. Hinges must be set in a straight line to prevent distortion. 5. Jambs and stops must be set square and plumb. 6. For best performance and to meet the standard Simpson warranty, any exterior door should be installed under an overhang or with sufficient protection. Adequate overhang depends on typical weather conditions of the area where the door is installed, but at the minimum means an overhang projecting a distance from the structure equal to one half the distance between the bottom of the door and the bottom of the overhang (see figure 1). 7. If an adequate overhang is not feasible, Simpson offers a selection of products warranted for this application, including a five-year limited warranty on doors featuring WaterBarrier® technology and a ten-year limited warranty on Nantucket® Collection doors. 8. Do not use dark colored stains or paints. 9. Immediately after cutting and fitting (before hanging), seal all cut surfaces and ends of door with an effective quality sealer. See exterior and interior finishing recommendation for complete instructions. 10. Prior to exterior exposure, doors must be finished with complete finish system. 11. To minimize heat loss and save energy, use weather stripping. Y X Figure 1 X = 1/2 Y FITTING & HANGING ONE YEAR EXTERIOR DOOR AND FIRE DOOR WARRANTY For doors used in an exterior application, other than as specified herein, and for fire-rated interior doors, this warranty shall survive for one year after the date of shipment from Simpson. This warranty applies to doors properly sealed, finished and, in the case of exterior applications, hung in a location protected from exposure to direct sun or rain under normal conditions. See specific Fitting and Hanging instructions. TEN YEAR NANTUCKET® COLLECTION LIMITED WARRANTY For Nantucket Collection doors—defined as using Nantucket construction methods—in Sapele Mahogany, Douglas Fir or Nootka Cypress wood species, this warranty shall survive for ten years after the date of shipment from Simpson. This warranty applies to doors properly sealed and finished per Simpson's Care and Finishing instructions. The ten year warranty on Nantucket Collection doors does not apply to doors used in commercial, hospitality or multi-family applications. Further, face-checking is considered a natural characteristic and shall not be considered a defect. The ten year warranty applies only to the original enduser and is not transferable. FIVE YEAR PERFORMANCE SERIES® WITH WATERBARRIER® TECHNOLOGY DOOR LIMITED WARRANTY For all doors that include WaterBarrier technology over the exterior surface of the door, this warranty shall survive for five years after the date of shipment from Simpson. This warranty applies to doors properly sealed and finished per Simpson’s Care and Finishing instructions. The five year warranty on doors with WaterBarrier technology does not apply to doors used in commercial, hospitality or multi-family applications. The five year warranty applies only to the original end-user and is not transferable. FIVE YEAR PERFORMANCE SERIES® WITH ULTRABLOCK® TECHNOLOGY DOOR LIMITED WARRANTY For all doors that include UltraBlock technology in the bottom of the door stiles, this warranty shall survive for five years after the date of shipment from Simpson. This warranty applies to the stiles and bottom rails of doors properly sealed, finished and, in the case of exterior applications, hung in a location protected from exposure to direct sun or rain under normal conditions. See specific Fitting and Hanging instructions. Other door components are subject to Simpson's one year limited warranty. FIVE YEAR LIMITED INSULATED GLASS WARRANTY Simpson Door Company warrants that standard clear insulated glass units will not, for a period of five (5) years after the date of shipment from Simpson, develop material obstruction of vision between the interior glass surfaces caused by failure of the hermetic seal. This warranty shall not apply to units with broken glass, glass units installed by others, or units that have retrofit films applied. Simpson’s liability under this warranty shall be limited to shipping a replacement glass unit. LIMITED LIFETIME INNERBOND® WARRANTY Simpson further provides a limited lifetime warranty on Innerbond panels against splitting through the entire panel due to rain, sun, weather, and other such factors exclusive of major calamity. In the event an Innerbond panel splits through, Simpson will ship a replacement door. If Simpson has discontinued manufacturing the door type/style with the Innerbond panel warranty claim, Simpson will issue a replacement door equal to or less than the original price of the original door purchase. Simpson Door Company (“Simpson”) warrants that each panel door bearing the Simpson brand and identification mark complies with Industry Standard NWWDA I.S.6. and all revisions in effect as of the date of manufacture, and Simpson further warrants, except as stated below, that each such door, at the time of the shipment from Simpson, is of good material and workmanship and free from defects that would render such door unserviceable or unfit for the ordinary, recommended use. The Simpson limited warranty applies to new doors other than those sold “as is”. Warranty periods for specific doors and door components, and exclusions, follow:
brosco.com 19 If you haven't found what you are looking for in this brochure, let your BROSCO Boise Cascade Account Manager help you create a one-of-a-kind door to fit your needs. From species selection to design, BROSCO Boise Cascade and Simpson can guide you through the process of creating a custom door. And you will receive the same great service and attention to detail you'd expect from both. SIMPSON SPECIAL ORDER AND CUSTOM DOORS
94467881 4/25 Since 1890, the BROSCO Boise Cascade name has represented our commitment to quality, value and service. We believe in providing low-maintenance, environmentally friendly, energy-efficient millwork products with our northeast regional architectural preferences. • Building Our Futures Together #BuiltByBROSCO For additional information, please visit brosco.com ~ simpsondoor.com
